Mitox 28LH-a - Specifications

28LH-a SELECT Hedgetrimmer
23
Original Instructions Version June 16
28LH-a_200616
Specifications
MODEL MITOX 28LH SELECT
Engine Type Air cooled 2-stroke gasoline engine
Model IE34F-4A
Displacement : ( cm3) 25.4 cc
Max. output 0.75 (kw) in accordance with ISO 8893
Idle speed: rpm (min
–1)
3100±400
Max. rpm (min –1) 9000
Fuel tank capacity 0.60L
Fuel Mixture (petrol 40 : Oil 1)
Carburettor Diaphragm type
Spark Plug LD L8RTF; CHAMPION RCJ7Y; NGK BPMR7A
Transmission Centrifugal clutch
Weight (Power Unit Only) 4.63kg
Weight ( Power Unit & Attachment) 7.31kg
EX-LH
Weight (Attachment Only) 2.68kg
Tooth Spacing 27mm
Reduction ratio 4 : 1
Cutting head Type Reciprocating double blade
Eective cut Length 510mm
