28LH-a SELECT Hedgetrimmer
29
Original Instructions Version June 16
28LH-a_200616
Parts List - Body
ID No. Part Number Description
1 MITBC431D.02.00-3 CLAMP
2 MITBC430D.03.02-00 HARNESS CLAMP LOOP
3 MIGB/T2671.2 M5X20 SCREW M5X20
4 MITBC430D.03.00-2 CLAMP
5 MIGB/T6170 M5 NUT M5
6 MITBC431SJ.03.02-00 OUTER SHAFT - UPPER
7 MITBC431DJ.03.03-00 COUPLING ASSEMBLY
8 MIGB/T2671.2 M5X25 SCREW M5X25
9 MIGB/T2671.2 M5X12 SCREW M5X12
10 MIGB/T5781 M6X50 BOLT M6X50
11 MIGB/T96 M6 WASHER M6
12 MITBC431DJ.03.03-7 LOCK KNOB
13 MIGB/T923 M6 NUT M6
14 MITBC431DJ.03.03-3 LOCK ASSY
56 MITBC431S.05.01-1 LOOP HANDLE UPPER
57 MIGB/T6170 M5 NUT M5
58 MITBC431S.05.01-2 HANDLE BASE
59 MITBC431S.05.01-3 HANDLE CLAMP
61 MIGB/T2671.2 M5X28 SCREW M5X28
62 MIGB/T93 M5 SPRING WASHER M5
63 MIGB/T97.1 5X12X1.5 WASHER 5X12X1.5
65 MIGB/T97.1 5X12X1.5 WASHER 5X12X1.5
66 MIGB/T845 ST4.8X19 TAPPING SCREW ST4.8X19
67 MI03.06.1.075 FOAM GRIP
68 MITBC430DJ.03.00-1 DRIVE SHAFT
69 MIGB/T6170 M5 NUT M5
70 MITBC431S.05.02-5 SPRING
71 MITBC431S.05.02-8 WIRE A
72 MITBC431S.05.02-9 WIRE B
73 MITBC431S.05.02-10 CONDUIT
