HT60D / HT70S Hedgetrimmer
41
Original Instructions Version Mar12
ID PART NUMBER DESCRIPTION QTY
31 MIGJB25D.00.00-5 FUEL TANK ABSORBER 2
32 MITBC431D.01.13.01-2 STOPPER 1
33 MITBC431D.01.13.01 FUEL CAP ASSY 1
35 MIGJB25D.00.00-7 WASHER 1
36 MIYD45.03.03-00 FUEL FILTER 1
37 MIGJB25D-2.03.00-2 FUEL PIPE 1
38 MIGJB25D-2.03.00-3 RETURN PIPE 1
39 MITBC431D.01.13.00-6 FUEL PIPE 2.5×5×95 1
40 MITBC431D.01.13.00-3 GROMMET 1
41 MIYD38-3.00.00-17 OIL PIPE CIRCLIP 1
42 MIYD38-3.03.06-00 BREATHER ASSEMBLY 1
43 MIYD62.02.00-3 STARTER HANDLE 1
44 MIGJB25D.02.00-3 ROPE 1
45 MIYD25.02.01-2 ROPE GUIDE 1
46 MITHT245D.02.01 RECOIL STARTER ASSY 1
47 MITBC261D.01.12.00-5 RECOIL SPRING 1
48 MITBC261D.01.12.00-4 RECOIL PULLEY 1
49 MITHT245D.02.01-2 TORSION SPRING 1
50 MITHT245D.02.01-3 RATCHET GEAR 1
51 MIGB/T9074.19
ST4.8X10
SCREW ST4.8×10 1
52 MIGB/T818 M5X16 SCREW 4
53 MITHT245D.02.00-4 TOP COVER 1
54 MIGB/T845 ST4.8X13 TAPPING SCREW ST4.8X13 1
55 MIGJB25D.00.01-00 CORD SPLINT 1
56 MIGJB25D-2.02.00-5 FRONT COVER 1
57 MIGJB25D-2.05.02-1 CABLE HOLDER 1
58 MIGB/T845 M4X14 SCREW M4×14 1
59 MIGJB25S.05.00-0A THROTTLE TRIGGER ASSY 1
HT70S Parts - Main Body
