129

16.4.1. Preparation for releasing the brakes

Before releasing the brakes, it is necessary to do the following operation.

1. Set the mode of the controller to “MANUAL”.

2. [TEACH] button is set to ON.

3. Push the enable switch.

4. Press the CAUTION button. Another person supports the Robot arm which releases brake.
