FX2NC Series Programmable Controllers Diagnostics 7.
7-18
FX
2NC
Counter
(256 pnts)
16 bit C0-C99 (100 pnts)
Battery backup
by Parameters16 bit C100-C199 (100 pnts)
32 bit C200-C219 (20 pnts)
Battery backup
by Parameters
32 bit C220-C234 (15 pnts)
32 bit High speed counter
C235-C245
C246-C250
C251-C255
Data register
(8000 pnts,
+ 256 pnts)
General D0-D199 (200 pnts)
Battery backup
by ParametersBattery backup D200-D511 (312 pnts)
Battery backup D512-D7999 (7488 pnts)
D1000-D7999
File register by Parameters
Special function D8000-D8255 (256 pnts)
Index V0-V7, Z0-Z7 (16 pnts)
Pointer
CJ (FNC 00), CALL (FNC 01) P0-P127 (128 pnts)
EI (FNC 04) I00

- I50

, I6

- I8

, I010 - I060 (6, 3, 6 pnts)
Nesting MC /MCR N0 - N7 (8 pnts)
Numbers 16 bit 32 bit
K -32,768 to 32,767 -2,147,483,648 to 2,147,483,647
H 0 to FFFFH 0 to FFFFFFFFH
