Mitsubishi Electric MELSEC iQ-R Series - Program Setter

1332
11 PROCESS CONTROL INSTRUCTIONS
11.3 Control Operation Instructions
Program setter
S.PGS
This instruction provides control output according to the SV and MV patterns.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
ENO:=S_PGS(EN,s1,s2,d1,d2);
FBD/LD
Instruction Execution condition
S.PGS
Operand Description Range Data type
(s1) Empty string specification
(Specify "" in ladder. Specify '' in ST or FBD/LD.)
 String
(d1) Block memory start device Refer to "Block memory". Word
(s2) Empty string specification
(Specify "" in ladder. Specify '' in ST or FBD/LD.)
 String
(d2) Loop tag memory start device Refer to "Loop tag memory". Word
EN Execution condition  Bit
ENO Execution result  Bit
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, R, ZR,
RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s1)   
(d1)         
(s2)   
(d2)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s1) (d1) (s2) (d2)
EN ENO
d1
d2
s1
s2
