Mitsubishi Electric MELSEC iQ-R Series - Converting 16-Bit Unsigned Binary Data to 32-Bit Signed Binary Data

410
6 BASIC INSTRUCTIONS
6.6 Data Conversion Instructions
Converting 16-bit unsigned binary data to 32-bit signed binary
data
UINT2DINT(P)
These instructions convert the specified 16-bit unsigned binary data to 32-bit signed binary data.
*1 The engineering tool with version "1.035M" or later supports the ST.
■Execution condition
Setting data
■Description, range, data type
■Applicable devices
Ladder ST
*1
ENO:=UINT2DINT(EN,s,d);
ENO:=UINT2DINTP(EN,s,d);
FBD/LD
Instruction Execution condition
UINT2DINT
UINT2DINTP
Operand Description Range Data type Data type (label)
(s) Binary data or the device where the binary data is stored 0 to 65535 16-bit unsigned binary ANY16_U
(d) Start device for storing the converted binary data  32-bit signed binary ANY32_S
EN Execution condition  Bit BOOL
ENO Execution result  Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)         
(d)         
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant) (Process)
(s) (d)
EN ENO
ds
