1 FUNCTIONS
1.12 Configuration Function
Log
Display communication logs and errors related to BACnet communication.
Displaying communication logs of BACnet
This function displays data that a BACnet module has been sent/received.
The maximum number of communication logs can be set in [Settings] [Basic Information] [BACnet Detail Setting] button
"System" "MaxComLogCount". (Page 281 System)
If the number of logs exceeds the maximum number of logs, the logs will be deleted in order from the oldest one, and a new
log is saved.
1. Select [Log] [BACnet Communication] to display the list of logs.
2. Click a [Log-n] button to display the details of the log.
Displaying BACnet communication errors
This function displays errors related to BACnet communication.
Up to 100 errors can be displayed.
If the number of errors exceeds 100, the errors will be deleted in order from the oldest one, and a new error is saved.
1. Select [Log] [Message].
To Next Page
