Troubleshooting related to network and connection
Symptom Check point Corrective action
Login screen does not appear. Is there any disconnection in the connection route? • Connect the cables properly.
• Replace the cables to new ones.
Is the CPU module right after powering ON or
resetting?
• The screen appears after 30 seconds after starting the
CPU module.
Is an IP address set to the personal computer? • Set the IP address of the personal computer and the
BACnet module to be on the same network. (Page 197
Network information)
Is the IP address duplicated? • Review the setting of the IP address.
Can the module communicate using Ping
command?
• Check if the IP address and the host name are correct.
• Check if the cable is disconnected.
Is there a firewall on the communication route? • Contact the network administrator to check the setting of
the firewall.
Is restoration performed? • Check if the IP address is changed by restoration.
Unable to log in. Are the user name and password correct? • Check if the case (upper or lower) is correct.
• When the user name or password is changed, log in with
the new user name or new password.
• Check if the login information is changed by restoration.
• If the login information has been forgotten, initialize the
BACnet module.
Unable to communicate with another
BACnet device.
Is the IP address duplicated? • Review the setting of the IP address.
Is the instance number of devices duplicated? • Review the instance number of the device.
Is the communication to the target BACnet device
established?
• Check the BACnet device of the communication target.
Is the BACnet module in stop state (the
background of the screen is yellow)?
• Restart the operation of the BACnet module. (Page
225 Restart)
Is the destination to send packet correct? • Check the destination in the communication log. (Page
196 Displaying communication logs of BACnet)
