Appendix 3 Buffer Memory
Connection status storage area
■Connection No.1 latest error code to connection No.64 latest error code (Un\G100 to Un\G163)
The latest error code for each connection is stored.
Status for each protocol
■IP packet (Un\G5000 to Un\G5029)
The IP status is counted in the range of 0 to 4294967295 (FFFFFFFH). (The number of receive aborts is counted in the range
of 0 to 65535 (FFFFH).)
■ICMP packet (Un\G5040 to Un\G5053)
The ICMP status is counted in the range of 0 to 4294967295 (FFFFFFFH).
■TCP packet (Un\G5080 to Un\G5085)
The TCP status is counted in the range of 0 to 4294967295 (FFFFFFFH).
■UDP packet (Un\G5120 to Un\G5125)
The UDP status is counted in the range of 0 to 4294967295 (FFFFFFFH).
■Receiving error (Un\G5160 to Un\G5165)
The receive error status is counted in the range of 0 to 4294967295 (FFFFFFFH).
Address Name
Un\G100 Connection No.1 latest error code
Un\G101 Connection No.2 latest error code
Un\G162 Connection No.63 latest error code
Un\G163 Connection No.64 latest error code
Address Name
Un\G5000 to Un\G5001 Received packet total count
Un\G5002 to Un\G5003 Received packet checksum error discard count
Un\G5004 to Un\G5005 Sent packet total count
Un\G5022 to Un\G5023 Simultaneous transmission error detection count (receive buffer full count)
Un\G5029 Receive abort count
Address Name
Un\G5040 to Un\G5041 Received packet total count
Un\G5042 to Un\G5043 Received packet checksum error discard count
Un\G5044 to Un\G5045 Sent packet total count
Un\G5046 to Un\G5047 Received echo request total count
Un\G5048 to Un\G5049 Sent echo replay total count
Un\G5050 to Un\G5051 Sent echo request total count
Un\G5052 to Un\G5053 Received echo reply total count
Address Name
Un\G5080 to Un\G5081 Received packet total count
Un\G5082 to Un\G5083 Received packet checksum error discard count
Un\G5084 to Un\G5085 Sent packet total count
Address Name
Un\G5120 to Un\G5121 Received packet total count
Un\G5122 to Un\G5123 Received packet checksum error discard count
Un\G5124 to Un\G5125 Sent packet total count
Address Description
Un\G5160 to Un\G5161 Framing error count
Un\G5162 to Un\G5163 Receive FIFO overflow count
Un\G5164 to Un\G5165 CRC error count
