Appendix 3 Buffer Memory
Time setting function (SNTP) area
■Time setting function operation result (Un\G11000)
■Time setting function execution time (Un\G11001 to Un\G11007)
■Time setting function required response time (Un\G11008)
■Time setting function (SNTP client) execution (Un\G11009)
IP packet transfer function area
■IP packet transfer latest data volume (Un\G11050 to Un\G11051)
■IP packet transfer maximum data volume (Un\G11052 to Un\G11053)
Address Description
Un\G11000 Stores the operation result of the time setting function.
0: Unexecuted
1: Success
FFFFH: Failure
Address Name Description
Un\G11001 Year Stores the year that the time setting function was executed.
Un\G11002 Month Stores the month that the time setting function was
executed.
Un\G11003 Day Stores the date that the time setting function was executed.
Un\G11004 Hour Stores the time (hour) that the time setting function was
executed.
Un\G11005 Minute Stores the time (minute) that the time setting function was
executed.
Un\G11006 Second Stores the time (second) that the time setting function was
executed.
Un\G11007 Day of the week Stores the day of the week that the time setting function
was executed.
0: Sunday
1: Monday
2: Tuesday
3: Wednesday
4: Thursday
5: Friday
6: Saturday
Address Description
Un\G11008 Stores the time required for the module to set the time after sending to the SNTP server.
Range: 0 to FFFEH (Unit: ms)
Address Description
Un\G11009 Executes the time setting function when b0 is turned on.
The time setting function can be executed at a random time from a program.
The function is not executed if b0 is turned on during execution of the time setting function.
This is valid only when "Use" is set for "Time Setting (SNTP Client)" under "Time Setting" in "Application Settings".
Address Description
Un\G11050 to Un\G11051 Stores the latest value (byte/s) of the total size (byte) per unit time (1 second) of the transferred IP address.
(The low-order 16-bit value is stored in the 1st word, and the high-order 16-bit value is stored in the 2nd word.)
Range: 0 to 4294967295 (FFFFFFFFH)
The value is 4294967295 (FFFFFFFFH) if the above value is exceeded.
Address Description
Un\G11052 to Un\G11053 Stores the maximum value (byte/s) of the total size (byte) per unit time (1 second) of the transferred IP packet.
(The low-order 16-bit value is stored in the 1st word, and the high-order 16-bit value is stored in the 2nd word.)
Range: 0 to 4294967295 (FFFFFFFFH)
The value is 4294967295 (FFFFFFFFH) if the above value is exceeded.
