APPENDICES APPENDIX
Appendix 7 When Connecting the Module to a Remote Head Module
Communication example
This section describes the communication example for when connecting the C24 to a remote head module.
System configuration example
No. Device configuration Network Protocol
(1) R04CPU 
RJ71GF11-T2 CC-Link IE Field Network 
(2) RJ72GF15-T2 CC-Link IE Field Network 
RJ71C24  CH1: Nonprocedural protocol or bidirectional protocol
CH2: Predefined protocol
(3) External device (personal
computer)
 Nonprocedural protocol or bidirectional protocol
(4) External device (temperature
controller)
 Predefined protocol
(1) (2) (3) (4)
