1 INTRODUCTION
1.4 Parts identification
1.4 Parts identification
HK-KT/HK-RT (1.0 kW - 2.0 kW) series
■Without an electromagnetic brake
■With an electromagnetic brake
HK-ST/HK-RT (3.5 kW - 7.0 kW) series
■Without an electromagnetic brake
■With an electromagnetic brake
Power supply/encoder connector
Motor
shaft
Encoder
Power supply/brake/encoder connector
Motor
shaft
Encoder
Power connector
Encoder connector
Encoder
Motor shaft
Electromagnetic brake connector
Encoder connector
Power connector
Encoder
Motor shaft
