Mitsubishi Electric MFZ-KA35VA User Manual

WALL-MOUNTED Cooling OnlyM series
C-51
REFRIGERANT SYSTEM DIAGRAM
WALL- MOUNTED
Indoor
heat
exchanger
Room temperature
thermistor
RT11
Indoor coil
thermistor
RT12
Distributor
Refrigerant pipe :15.88
(with heat insulator)
Refrigerant pipe :6.35
(with heat insulator)
Stop valve
Capillary tube
:3.0X:1.8X500
Compressor
Stop valve
(with service port)
Outdoor
heat
exchanger
Refrigerant flow in cooling
Muffler
#100
Muffler
INDOOR UNIT
MS-GA60VB
OUTDOOR UNIT
MU-GA60VB
MS-GE50VB
Indoor
heat
exchanger
Room temperature
thermistor
RT11
Refrigerant pipe 12.7
(with heat insulator)
Indoor coil
thermistor
RT12
Refrigerant pipe 6.35
(with heat insulator)
Distributor
Refrigerant flow in cooling
INDOOR UNIT
Outdoor
heat
exchanger
Capillary tube
3.0 x 1.6 x 450
Strainer
#100
Stop valve
(with service port)
Compressor
Muffler
Stop valve
Flared connection
Flared connection
MU-GE50VB
OUTDOOR UNIT
Unit: mm

Mitsubishi Electric MFZ-KA35VA Specifications

General

Cooling Capacity	3.5 kW
Heating Capacity	4.0 kW
Power Supply	220-240 V, 50 Hz
Energy Efficiency Class (Cooling)	A++
Energy Efficiency Class (Heating)	A+
Seasonal Energy Efficiency Ratio (SEER)	6.10
Outdoor Unit Noise Level	49 dB
Operating Temperature (Cooling)	-10 to +46 °C
Operating Temperature (Heating)	-15 to +24 °C
