SPECIFICATION
3
Outdoor model MXZ-3E54VA
Outdoor unit power supply
Single phase
220 -230 - 240 V, 50 Hz / 220V, 60Hz
3
System
Indoor units number 2 to 3
Piping total length m Max. 50
Connecting pipe length m Max. 25
Height difference (Indoor ~ Outdoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Height difference (Indoor ~ Indoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Function Cooling Heating
Capacity Rated frequency (Min.-Max.)
2 kW 5.4 (2.9 - 6.8) 7.0 (2.6 - 9.0)
Breaker capacity A 25
Electrical
data
Power input (Total) 1, 2 W 1,350 1,590
Running current (Total)
1, 2 A 6.2 - 5.9 - 5.7 7.3 - 7.0 - 6.7
Power factor (Total)
1, 2% 99
Starting current (Total)
1, 2 A 7.0
Coeffi cient of performance (C.O.P) (Total)
1, 2 4.00 4.40
Compressor
Model SNB130FGBH1T SIC-82FX-F764-1
Output W 1,400
Current
1, 2 A 5.72 6.62
Refrigeration oil (Model) L 0.7 (NEO22)
Fan
motor
Model
E1
,
ET1
,
ER1
:
SIC-71FW-F764-2
E2
,
ET2
,
ER2
: SIC-82FX-F764-1
Current
1, 2 A 0.2
Dimensions W x H x D mm 840 x 710 x 330
Weight kg 58
Special
remarks
Air fl ow (Rated) m
3
/h 2,334 2,376
Sound level (Rated) dB(A) 50 53
Fan speed (Rated) rpm 650 660
Refrigerant fi lling capacity (R410A) kg 2.7
1 Measured under rated operating frequency.
2 When connected with indoor units below.
MSZ-EF18VE + MSZ-EF18VE + MSZ-EF18VE
3
220 and 240 V are only -
E2
,
ET2
and -
ER2
.
NOTE: Test conditions are based on ISO 5151. (Refrigerant piping length (one way): 5 m)
COOLING INDOOR Dry-bulb temperature 27.0 °C Wet-bulb temperature 19.0 °C
OUTDOOR Dry-bulb temperature 35.0 °C Wet-bulb temperature 24.0 °C
HEATING INDOOR Dry-bulb temperature 20.0 °C
OUTDOOR Dry-bulb temperature 7.0 °C Wet-bulb temperature 6.0 °C
