8
Outdoor model MXZ-4E83VA
Outdoor unit power supply
Single phase
220 -230 - 240 V, 50 Hz / 220V, 60Hz
3
System
Indoor units number 2 to 4
Piping total length m Max. 70
Connecting pipe length m Max. 25
Height difference (Indoor ~ Outdoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Height difference (Indoor ~ Indoor) m Refer to 7 REFRIGERANT SYSTEM DIAGRAM.
Function Cooling Heating
Capacity Rated frequency (Min.-Max.)
2 kW 8.3 (3.7 - 9.2) 9.3 (3.4 - 11.6)
Breaker capacity A 25
Electrical
data
Power input (Total) 1, 2 W 2,440 2,000
Running current (Total)
1, 2 A 11.2 - 10.7 - 10.3 9.2 - 8.8 - 8.4
Power factor (Total)
1, 2% 99
Starting current (Total)
1, 2 A 10.7
Coeffi cient of performance (C.O.P) (Total)
1, 2 3.40 4.65
Compressor
Model SNB220FAGMC
Output W 2,200
Current
1, 2 A 10.1 8.1
Refrigeration oil (Model) L 0.7 (FV50S)
Fan
motor
Model
E1
,
ET1
: SIC-81FW-D888-9
E2
,
ET2
,
ER1
,
E3
,
ET3
,
ER2
: SIC-88FWJ-D888-1
E2
,
ET2
,
ER1
,
E3
,
ET3
,
ER2
,
E4
,
ET4
,
ER3
: SIC-88FWJ-D888-4
Current
1, 2 A 0.3
Dimensions W x H x D mm 950 x 796 x 330
Weight kg
E1
,
ET1
: 62 /
E2
,
ET2
,
ER1
,
E3
,
ET3
,
ER2
,
E4
,
ET4
,
ER3
: 63
Special
remarks
Air fl ow (Rated) m
3
/h 3,336 3,336
Sound level (Rated) dB(A) 49 51
Fan speed (Rated) rpm 620 620
Refrigerant fi lling capacity (R410A) kg 2.99
1 Measured under rated operating frequency.
2 When connected with below indoor units.
MSZ-EF18VE + MSZ-EF18VE + MSZ-EF22VE + MSZ-EF25VE
3
220 and 240 V are only -
E4
,
ET4
and -
ER3
.
NOTE: Test conditions are based on ISO 5151. (Refrigerant piping length (one way): 5 m)
COOLING INDOOR Dry-bulb temperature 27.0°C Wet-bulb temperature 19.0°C
OUTDOOR Dry-bulb temperature 35.0°C Wet-bulb temperature 24.0°C
HEATING INDOOR Dry-bulb temperature 20.0°C
OUTDOOR Dry-bulb temperature 7.0°C Wet-bulb temperature 6.0°C
