APPX
Appendix 2 Remote Register
225
A
Input module (32-point module)
■Remote register (RWr)
*1 The area is used for the system.
■Remote register (RWw)
*1 The area is used for the system.
Device number Name
CC-Link IE TSN Network synchronous communication function
Not used Synchronous X/Y control
mode
Synchronization cycle
timing control mode
Set time synchronization
control mode
RWr0 Use prohibited Use prohibited Use prohibited Use prohibited
RWr1 Error code Error code Error code Error code
RWr2 Function selection status area Function selection status area Function selection status area Function selection status area
RWr3 Use prohibited Use prohibited Use prohibited
*1
Use prohibited
*1
RWr4 Use prohibited Use prohibited Use prohibited Input ON/OFF information X0 to
XF
RWr5 Use prohibited Use prohibited Use prohibited Input ON/OFF information X10
to X1F
RWr6 to RWrF Use prohibited Use prohibited Use prohibited Use prohibited
RWr10, RWr11 Use prohibited Use prohibited Synchronization input timing
information X0 OFF to ON
Input time information X0
RWr12, RWr13 Use prohibited Use prohibited Synchronization input timing
information X0 ON to OFF

RWr8C, RWr8D Use prohibited Use prohibited Synchronization input timing
information X1F OFF to ON
Input time information X1F
RWr8E, RWr8F Use prohibited Use prohibited Synchronization input timing
information X1F ON to OFF
Device number Name
CC-Link IE TSN Network synchronous communication function
Not used Synchronous X/Y control
mode
Synchronization cycle
timing control mode
Set time synchronization
control mode
RWw0 Module operation area Module operation area Module operation area Module operation area
RWw1, RWw2 Use prohibited Use prohibited Use prohibited Use prohibited
RWw3 Use prohibited Use prohibited Use prohibited
*1
Use prohibited
*1
RWw4 Use prohibited Use prohibited Use prohibited ON/OFF selection flag X0 to XF
RWw5 Use prohibited Use prohibited Use prohibited ON/OFF selection flag X10 to
X1F
RWw6 to RWw8F Use prohibited Use prohibited Use prohibited Use prohibited
