Mitsubishi Electric Q06HCPU - Appendix 13.4 Extension Base Units

696
Appendix 13.4 Extension base units
(1) Q52B
(2) Q55B
(3) Q63B
Unit: mm
Unit: mm
Unit: mm
I/O0 I/O1
OUTIN
44.1
7.5
98
7 80±0.3
15.5
106
83.5±0.3
4-mounting screws (M4×14)
I/O2I/O1I/O0 I/O3 I/O4
OUTIN
44.1
7.5
98
7 80±0.3
15.5
189
167±0.3
4-mounting screws (M4×14)
I/O0
FG
I/O2I/O1
POWER
5V
SG
OUTIN
44.1
7.5
98
7 80±0.3
15.5
189
167±0.3
4-mounting screws (M4×14)
