12.7 When a CPU Module Stop Error Occurs
12
CONCEPT OF MULTIPLE CPU SYSTEM
(3) Restoring the system
When a C Controller is CPU No.1, restore the system in the following procedure.
1) Check the No. of the faulty CPU and the error cause on the System
information screen opened from the <<Module monitoring>> tab of C
Controller setting utility.
2) Remove the cause.
3) Either reset CPU No.1 or restart the multiple CPU system (power supply
on off on).
By resetting CPU No.1 or restarting the multiple CPU system, all the CPUs in the
multiple CPU system are reset and the system is restored.
For restoration of the system where CPU No.1 is a programmable controller CPU,
refer to the following.
QCPU User's Manual (Multiple CPU System)
