4 OPERATION CONTROL PROGRAMS
4.13 Comparison Operations
Less than: <
Setting data
■Usable Data
: Usable
■Description, data type of result
Processing details
• The result is true if the data specified with (S1) is less than the data specified with (S2).
• When (S1) and (S2) differ in data type, the data of the smaller data type is converted into that of the greater type before
comparison is performed.
Operation error
An operation error will occur if:
• (S1) or (S2) is an indirectly specified device and its device No. is outside the range.
Program example
■Program which compares whether #0 is less than D0 or not
Format Number of basic steps Usable steps
F/FS G
(S1)<(S2) 7 
Setting
data
Usable Data
Bit
device
Word device Constant Calculation
expression
Bit
conditional
expression
Comparison
conditional
expression
16-bit
integer
type
32-bit
integer
type (L)
64-bit
floating
point
type (F)
16-bit
integer
type
(K/H)
32-bit
integer
type
(K/H, L)
64-bit
floating
point
type (K)
(S1)   
(S2)   
Setting data Description Data type of result
(S1) Data which will be compared Logical type (true/false)
(S2)
#0 < D0
20
<
10#0
D0
(True)
