2 PARAMETER SETTINGS
2.2 Basic Setting
*1 The item can be set only in the parameter setting. It cannot be changed from the program.
Counter operation mode
*1
• 0: Pulse count mode (default value)
• 1: Pulse measurement mode
• 2: PWM output mode
Preset value setting -2147483648 to 2147483647 (default value: 0) Page 62 CH1 Preset value setting
Coincidence output point No.1 -2147483648 to 2147483647 (default value: 0) Page 62 CH1 Coincidence output point No.1
setting
Coincidence output point No.2 -2147483648 to 2147483647 (default value: 0) Page 62 CH1 Coincidence output point No.2
setting
Ring counter upper limit value setting -2147483648 to 2147483647 (default value: 0) Page 65 CH1 Ring counter upper limit value setting
Ring counter lower limit value setting -2147483648 to 2147483647 (default value: 0) Page 65 CH1 Ring counter lower limit value setting
Item Setting range Reference
