484
-
'12 • PAC-T-173
Model
Item
FDC140VSX
Power source 380-415V 3N
~
50Hz / 380V 3N
~
60Hz
Operation data Cooling Heating
Nominal capacity kW 14.0 [ 5.0 (Min.)
~
16.0 (Max.)] 16.0 [ 4.0 (Min.)
~
20.0 (Max.)]
Sound Pressure Level dB(A) Cooling : 49 Heating : 52
Exterior dimensions
Height × Width × Depth
mm 1,300 × 970 × 370
Exterior appearance
(Munsell color)
Stucco White
(4.2Y7.5/1.1) near equivalent
Net weight kg 105
Refrigerant equipment
Compressor type & Q'ty
RMT5134MDE3 × 1
Starting method Direct line start
Refrigerant oil 0.9 M-MA68
Heat exchanger M shape fin & inner grooved tubing
Refrigerant control Electronic expansion valve
Air handling equipment
Fan type & Q'ty
Propeller fan × 2
Motor <Starting method> W 86 × 2 < Direct line start >
Air flow (Standard) CMM 100
External static pressure 0
Shock & vibration absorber Rubber sleeve (for Compressor)
Electric heater W 20 (Crank case heater)
Safety equipment
Internal thermostat for fan motor
Abnormal discharge temperature protection.
Installation data
Refrigerant piping size
mm
Liquid line :
φ
9.52 (3/8")
Gas line :
φ
15.88 (5/8")
Connecting method Flare piping
Refrigerant line (one way) length
Max.100m
Vertical height difference between
outdoor unit and indoor unit
Max.30m (Outdoor unit is higher)
See page 152,153
Max.15m (Outdoor unit is lower)
Refrigerant Quantity R410A 4.5kg in outdoor unit (incl. the amount for the piping of : 30m)
Drain Holes size
φ
20 × 3pcs
Insulation for piping Necessary (both Liquid & Gas lines)
IP code IP24
Standard Accessories Edging
Adapted to RoHS directive
Item Indoor air temperature Outdoor air temperature
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C 7˚C 6˚C
Notes (1) The data are measured at the following conditions.
(2) This packaged air-conditioner is manufactured and tested in conformity with the ISO.
(3) Sound pressure level indicates the value in an anechoic chamber. During operation
these value are somewhat higher due to ambient temperature.
(4) The operation data indicates when the air-conditioner is operated at 400V50Hz or 380V60Hz.
PJF000Z296
