5-50
Comfort controls
5
SUB PUNCH (subwoofer volume control) (if so
equipped)
To select the desired deep bass level.
TYPE (acoustic characteristic selection)
To select the desired acoustic characteristic.
Adjust
Mode
Adjust
Level
Sound control switch operation
Counterclock-
wise turn
Clockwise turn
SUB
PUNCH
1 to 6 Weaker Stronger
TYPE
NORMAL ↔ POP ↔ ROCK ↔ HIP-HOP ↔
COUNTRY
FIELD NORMAL ↔ STAGE ↔ LIVE ↔ HALL
BASS
-6 to 6 Weaker StrongerMID
TREBLE
FADER F11 to R11
R (Rear)
increases
F (Front)
increases
BALANCE L11 to R11
L (Left)
increases
R (Right)
increases
Acoustic characteristic Description
NORMAL Sounds good for all types of music.
POP Tight bass and high frequency sound.
ROCK
Tuned for hard rock and heavy metal
with powerful drums, guitars, and
vocals.
HIP-HOP
Deep bass punch and wll-defined
vocals.
COUNTRY Enhanced main vocals.
