Mitsubishi diesel engines - Thermoswitch; Water Pump

COOLING SYSTEM - DISASSEMBLY, INSPECTION AND REASSEMBLY
5 - 7
2. Thermoswitch
Inspecting the thermoswitch
Dip the temperature sensing element of the
thermoswitch in oil as illustrated. While
warming the oil, measure the resistance at the oil
temperature of 105℃ (221°Ｆ). If the measured
value is substantially out of the standard value,
replace the thermoswitch.
Unit: MΩ
Temperature Standard value
105℃ (221°Ｆ)
30
This is a “hot” operation. Pay every attention to
prevent burns and fire.
3. Water Pump
Inspecting the water pump
Rotate the impeller and the shaft for any noise or
binding. If faulty, replace the entire pump
assembly.
Inspecting the thermoswitch
Inspecting the impeller and shaft
for smooth rotation
+-
