Connector disconnected or improperly
connected
1650256
Defective connector contact
16’30254
0 0 0 0 0 2 1 9
CONNECTOR INSPECTION SERVICE POINTS
VISUAL INSPECTION
l Connector is disconnected or improperly connected
l Connector pins are pulled out
l
Harness wire breakage due to harness tension at terminal
section
l
Low
contact pressure
between male and female terminals
l
Low connection pressure due to rusted terminals or foreign
matter lodged in terminals
CONNECTOR PIN INSPECTION’
If the connector pin stopper is damaged, the terminal connec-
tions (male and female pins) will not be perfect ‘even when
the connector body is connected, because the may pull,
out of the back side of the connector. Therefore, gently pull
the wires one by one to make
no pins pull out’
of the connector.
.
TSB Revision
1
CON NE CTO R E NGA GE MEN T IN SP ECT IO N
Use the special tool (connector pin connection pressure in-
spection harness of the inspection harness set) to inspect’
the engagement of the male pins and female pins. [Pin drawing
force 1 Ibs.) or more]
.
,
