2-14
POWER TRAIN
-
Manual Transaxle
THIRD GEAR
The 3-4 synchronizer sleeve moves forward to
en-
gage the third-speed gear clutch teeth. Input power
goes through the input shaft, into the 3-4
synchroniz-
er hub. The hub turns the synchronizer sleeve, third
speed gear and the output shaft. The output shaft
pinion gear turns the differential ring gear. The gear
ratio for third is
1.36:1
,d
3rd speed
gear
/
/
In
:
i-1
‘&m&J
L,
nchronizer
126
128
