Mitsubishi ECLIPSE User Manual

3-34
Features and controls
3
5. Push the left and right release buttons (A) to unlock the
latch handles (B) and cause them to slightly rise.
6. Pull the latch handles (B) toward you until they lock in
position.
N
OTE
● Make sure the latch handles (B) are securely locked in
place. Operating the electric convertible top without first
locking the latch handles in position could cause the elec-
tric convertible top to malfunction.
● If you pull the driver’s-side latch handle (B) while listen-
ing to the audio system, an audible beep will sound and
the audio system’s sound equalization will change to set-
tings that are optimized for operation with the electric
convertible top open.
A
B
B
BK0098300US.book 34 ページ ２００８年１２月８日 月曜日 午前１１時３７分
