Comfort controls
5-3
5
Changing the mode selection
N00736400451
To change the position and amount of air flowing from the
vents, turn the mode selection dial. (Refer to “Mode selection
dial” on page 5-7, 5-17.)
These symbols are used in the next several illustrations to dem-
onstrate the quantity of air coming from the vents.
: Small amount of air from the vents
: Medium amount of air from the vents
: Large amount of air from the vents
Face position
Air flows only to the upper part of the passenger compartment.
Foot/Face position
Air flows to the upper part of the passenger compartment, and
flows to the leg area.
OTE
● With the mode selection dial between the “ ” and “ ”
positions, air flows mainly to the upper part of the passen-
ger compartment. With the mode selection dial between
the “ ” and “ ” positions, air flows mainly to the leg
area.
