ELECTRICAL SYSTEM
Lighting switch and turn signal switch
Lighting switch and
turn signal switch
Horn contact
Horn
Steering angle sensor
Forward-reverse
selector switch
T- 3
L-2
L-4
L-5
L-3
L-1
T- 2
T- 1
4
2
1
4
2
3
1
5
209627
Lighting and
turn signal lever
Boot
Horn contact
Steering angle sensor
Boot
Forward-reverse lever
Lighting switch, turn signal switch
Forward of truck
209625
Lighting switch,
turn signal switch
Forward of truck
Forward-reverse
selector switch
209626
