Mitsubishi FD30N User Manual

HOW TO USE THIS MANUAL
Truck models covered in this manual:
• MC Truck (Mechanical Control System)
Mechanically controlled hydraulic system (conventional lever system)
• FC Truck (Finger-tip Control System)
Electronically controlled hydraulic system
• Gasoline Engine Truck (FG) . . . . . . . . . . . . . . . . . . Equipped with K21 or K25 Gasoline Engine
• Diesel Engine Tuck (FD) . . . . . . . . . . . . . . . . . . . . Equipped with S4Q2 or S4S Diesel Engine
•Powershift Truck . . . . . . . . . . . . . . . . . . . . . . . . . . . Equipped with Powershift Transmission
FC lever box
Lever
Electromagnetic
control valve
Hydraulic transducer
Same as MC Truck except
electronic control system
Electric wiring
Controller
209602
Lever
Control
valve
Flow regulator
valve
209601
MC Truck
FC Truck
