HOW TO USE THIS MANUAL (continued)
(Removal, Installation, Assembly and Disassembly)
Disassembly diagram (example)
Suggestion for disassembling
1. Output shaft, Removing
Remove output shaft using a special tool.
Service Data
A: Standard Value
B: Repair or Service Limit
209603
Sequence
1Cover , Bolt, Washer (part name)
2 Snap ring ................ (part name)
A
0.11 to 0.28 mm
Gear Backlash
(0.0043 to 0.0110 in.)
B 0.5 mm (0.020 in.)
209604
Disassembling sequence
Procedures are described in the text.
To Next Page
