HOW TO USE THUS MANUAL(continued)
Disassembly diagram(example)
Suggestions for Disassembly
Output shaft, Removing
Remove output shaft using a special tool.
Service Data
1
2
213445
Sequence
1 Cover, Bolt, Washer (part name)
2 Out put shaft assembly (part name)
213446
Unit:mm(in.)
Gear Backlash
A
0.11 to 0.28
(0.004 to 0.011)
B
0.5
(0.012)
A: Standard value B: Repair or Service Limit

Mitsubishi FG50CN Specifications

General

Brand	Mitsubishi
Model	FG50CN
Category	Forklifts
Language	English
