A: Standard value B: Repair or service limit
HOW TO READ THIS MANUAL
Disassembly diagram
(example)
Suggestion for disassembly
(1) Output shaft removal
Symbols or abbreviations
OP ...................Option
R1/4.................Taper pipe thread (external) 1/4 inch (formerly PT1/4)
Rc1/8 ...............Taper pipe thread (internal) 1/8 inch (formerly PT1/8)
G1/4A..............Straight pipe thread (external) 1/4 inch (formerly PF1/4-A)
Rp1/8...............Straight pipe thread (internal) 1/8 inch (formerly PS1/8)
Clearance between
cylinder and piston
0.020 to 0.105
(0.00079 to 0.00413)
gram is followed by
and Suggestions for
Each disassembly dia
Disassembly sequence
disassembly.
Sequence
1.
Cover, Bolt, Washer (part name)
2.
Output shaft (part name)
To Next Page
