11-6 In cold weather

6. Ensure that hooks and are flat on the tire

sidewalls. Also make sure that the chains are

not twisted.

7. Fasten extra chain links with a metal wire to pre-

vent them from hitting against other vehicle

parts.

8. Fit spring band . Attach the hooks of spring

band on the chain at even intervals with the

hook ends facing outward.

9. After driving the vehicle for 5 to 10 minutes,

check the chains for looseness or disconnected

hooks.

Z09329

Z09330
