9 Creating Programs (for FX3G, FX3U and FX3UC PLCs)
9.2 Contents of Related Devices
9.2 Contents of Related Devices
The tables below show devices used for inverter communication in FX3G, FX3U and FX3UC PLCs.
1. Bit devices
R: Read only (used as a contact in program)
*1. Cleared when the power is turned off and on.
*2. Cleared when the PLC mode is changed from STOP to RUN.
*3. The IVBWR instruction is supported only in FX
3U and FX3UC PLCs.
2. Word devices
R: Read only
W: Write only
R/W: Read or Write
*1. Cleared when the power is turned off and on.
*2. Cleared when the PLC mode is changed from STOP to RUN.
*3. The IVBWR instruction is supported only in FX
3U and FX3UC PLCs.
Device No.
Name Description R/W
ch1 ch2
M8029 Instruction execution complete
Turns ON when execution of inverter communication
instruction is completed, and remains ON for 1 scan.
Turns ON also when execution of instruction is
completed if inverter communication error flag
(M8152 or M8157) turns ON.
R
M8063 M8438
Serial communication error
*1
Turns ON when an error occurs in any type of
communication.
R
M8151 M8156 Inverter communicating
Remains ON while inverter communication is being
executed.
R
M8152 M8157
Inverter communication error
*2
Turns ON when an error occurs during
communication with an inverter.
R
M8153 M8158
Inverter communication error latch
*2
Turns ON when an error occurs during
communication with an inverter.
R
M8154 M8159
IVBWR instruction error
*2, *3
Turns ON when an error is caused by IVBWR
instruction.
R
Device No.
Name Description R/W
ch1 ch2
D8063 D8438
Error code for serial communication
*1
Stores a communication error code. R
D8150 D8155
Inverter communication response
waiting time
Sets the response wait time of inverter
communication.
R/W
D8151 D8156
Step number of instruction executing
inverter communication
Stores the step number of an instruction during
inverter communication.
R
D8152 D8157
Error code for inverter
communication
*2
Stores an inverter communication error code. R
D8153 D8158
Step where inverter communication
error occurred
*2
Latches a step number in which inverter
communication error has occurred.
R
D8154 D8159
Error parameter number of IVBWR
instruction
*2, *3
Stores a parameter number in which an IVBWR
instruction error has occurred.
R
