Mitsubishi HMA100V Technical Manual

For Home Owners
Information about the installation
-
41
-
'10 • HM-T-149
Information about the installation
Product information
Hydrolution is a complete modern heat pump system that
offers effective technical energy saving and reduced carbon
dioxide emissions. Heat production is safe and economical
with integrated hot water heater, immersion heater, circulation
pump and climate system in the indoor unit.
The heat is retrieved from the outdoor air through outdoor unit,
where the refrigerant circulated in a closed piping system
transfers the heat from the heat source (outdoor air) to indoor
unit.
This eliminates the for holes and coils in the ground.
Features of
Hydrolution
■ Optimal annual heating factor thanks to the inverter
controlled compressor.
■ Outdoorunitwithcompactdimensions.
■ Speedcontrolledsystempumpthatsuppliestheheatpump
withsuitablesystemow.
■ Optimizedoperatingcosts.Thespeedofthecompressoris
adjusted according to the demand.
■ Integratedcoilwaterheaterinindoorunit.
■ Integratedclockforschedulingextrahotwaterandtemperature
lowering/increasing the supply water temperature.
■ Preparedforcontroloftwoheatingsystems.
■ Integratedactivecoolingfunction.
■ Possibletoconnectexternalheatsources.
Principle of operation
Hydrolution
1
2
4
3
Function
Hydrolution is a system that can produce heating, hot water
and cooling.
Theprincipleduringheatingcanbesimpliedasfollows:
1. The refrigerantin outdoor unit takes the heat from the
outdoor air and is compressed to higher temperature by the
compressor.
2. The hot refrigerant (now in gas state) is routed into
indoor unit.
3. The refrigerant releases the heat for further distribution in
the system.
4. The refrigerant (now in liquid state) is routed back to
outdoor unit and the process is repeated.
By reversing the entire process, and thereby the refrigerant in
outdoorunittakestheheatfromthewaterandreleasetheheat
to the outdoor air, the heat pump can cool instead if necessary.
Indoorunitdetermineswhenoutdoorunitistoworkandnotto
work, usingthecollateddatafrom thetemperaturesensor.In
the event of extra heat demands, indoor unit can connect
additional heat source in the form of the internal immersion
heater, or any connected external heat source.
