Service
-
187
-
'10
•
HM-T-149
FDCW71VNX
2.
Open the control box cover
.
power OFF
.
3.
Loosen 4 screws
and remove the control PCB
Control PCB (PWB1)
1.
Open the top panel
Note: Be sure to do this
work after elapsing
3 minutes from
4.
Disconnect all connectors
CNF
AN
CNA1
CNN
CNS
CNPS
CNQ1
CNQ2
4 screws
CNR
CNEEV2
CNEEV1
CNH
CNW
CNTH
CNW2
Control PCB
Control box
CNA2
CNIP
CNB
CNG1
CN13
CNI1
S
W
4
Component replacement
187
189
