Menu 1.10.9 [S] HW reg value for xP
Here you select the breaking point when the ow is no longer
linear to the control signal in the heating medium pump.
Setting range: 1 – 100
Default value: 40
Menu 1.10.10 [S] Return
Return to Menu 1.10.0.
Menu 1.11.0 [S] CompFreq HW settings
The compressor frequency during hot water charging is shown
here.
Settings can be made regarding the compressor frequency
during hot water charging in the submenus to this menu.
Menu 1.11.1 [S] CompFreq HW set
Here you select the compressor frequency for hot water charg-
ing during manual control.
This setting is valid only when “On” is selected in Menu 1.11.2.
Menu 1.11.2 [S] CompFreq manual
Select “On” to control the compressor frequency for hot water
charging manually.
Setting range: Off, On
Default value: Off
Menu 1.11.3 [S] CompFreq at +20
The compressor frequency for hot water charging at an outdoor
air temperature of 20 °C is selected here.
Menu 1.11.4 [S] CompFreq at -5
The compressor frequency for hot water charging at an outdoor
air temperature of -5 °C is selected here.
Menu 1.11.5 [S] Return
Return to Menu 1.11.0.
Menu 1.12 [N] Return
Return to Menu 1.0.
2.0 [N] Supply temp.
Menu 2.1.0 [N] Heating settings
Heating settings are made in the sub-menus for this menu.
Menu 2.1.1 [N] Offset heating/Total
The selected heating curve offset is shown here.
The total offset of the heat curve is also shown here. It include
schedule, outer compensation and any room control.
Note! The value is changed using the “Heating curve offset” knob.
Setting range: -10 – 10
Menu 2.1.2 [N] Heating curve
The selected heating curve is shown here. At value 0, the
function “Own heat curve” is activated, see Menu 2.1.3.0.
Setting range: 0 – 20
Default value: 9
Menu 2.1.3.0 [U] Own heating curve
Here you can select your own curve definition. This is an
individual linear curve with one break point. You select a break
point and the associated temperatures.
Note! The “Heating curve” in Menu 2.1.2 must be set to 0 to
activate this function.
Menu 2.1.3.1 [U] Supply temp.at +20
The supply temperature at an outdoor air temperature of
+20 °C is selected here.
Setting range: 0 – 80* °C
Default value: 20 °C
* Limited by Menu 2.3 Max supply temp.
Menu 2.1.3.2 [U] Supply temp.at -20
The supply temperature at an outdoor air temperature of -20 °C
is selected here.
Setting range: 0 – 80* °C
Default value: 35 °C
* Limited by Menu 2.3 Max supply temp.
Menu 2.1.3.3 [U] Buckling temperature
Here you select at what outside air temperature the break point
shall occur.
Setting range: -15 – 15 °C
Default value: 0 °C
Menu 2.1.3.4 [U] Supply t. at buckl.
You set the calculated supply temperature for the break point here.
Setting range: 0 – 80* °C
Default value: 30 °C
* Limited by Menu 2.3 Max supply temp.
Menu 2.1.3.5 [U] Return
Return to Menu 2.1.3.0.
FDCW71 FDCW100 FDCW140
Setting range (Hz) 20 – 118 25 – 85 20 – 120
Default value (Hz) – – –
FDCW71 FDCW100 FDCW140
Setting range (Hz) 20 – 118 25 – 85 20 – 120
Default value (Hz) 100 80 100
FDCW71 FDCW100 FDCW140
Setting range (Hz) 20 – 118 25 – 85 20 – 120
Default value (Hz) 60 40 60
To Next Page
