32
Type
Rated current In (A)
Rated insulation voltage Ui (V) AC
Low-inst
Standard
Mag-Only
(Inst trip only)
Generator
690V
500V
440V
400V
230V
Frame (A)
AC Breaking
capacity (kA rms)
IEC60947-2
Icu/Ics
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Automatic tripping
device
Rating (A) and
Inst. (A)
Number of poles
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Solid-state
Adjustable ampere rating
Adjustable short time delay pick up
Fixed instantaneous pick up
Short time delay pick up current
Variation is within ±10% of the setting current
5-7.5-10 In
500 2500-3750-5000
600 3000-4500-6000
700 3500-5250-7000
800 4000-6000-8000
900 4500-6750-9000
1000 5000-7500-10000
Instantaneous pick up current 20000
NF1000-SS
1000
500-600-700-800-900-1000
690
25/13
65/33
85/43
85/43
125/63
34
34
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
34
Variation is within ±10% of the setting current
5-7.5-10 In 3-4.5-6 In 2-3-4 In
500 2500-3750-5000 1500-2250-3000 1000-1500-2000
600 3000-4500-6000 1800-2700-3600 1200-1800-2400
700 3500-5250-7000 2100-3150-4200 1400-2100-2800
800 4000-6000-8000 2400-3600-4800 1600-2400-3200
900 4500-6750-9000 2700-4050-5400 1800-2700-3600
1000 5000-7500-10000 3000-4500-6000 2000-3000-4000
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
Variation is within ±10% of the setting current
3-4.5-6 In 2-3-4 In
500 1500-2250-3000 1000-1500-2000
600 1800-2700-3600 1200-1800-2400
700 2100-3150-4200 1400-2100-2800
800 2400-3600-4800 1600-2400-3200
900 2700-4050-5400 1800-2700-3600
1000 3000-4500-6000 2000-3000-4000
34
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
Variation is within ±10% of the setting current
5-7.5-10 In
500 2500-3750-5000
600 3000-4500-6000
700 3500-5250-7000
800 4000-6000-8000
900 4500-6750-9000
1000 5000-7500-10000
+4000
–2000
