Mitsubishi NF800-CEP User Manual

35
Type
Rated current In (A)
Rated insulation voltage Ui (V) AC
Low-inst
Standard
Mag-Only
(Inst trip only)
Generator
690V
500V
440V
400V
230V
Frame (A)
AC Breaking
capacity (kA rms)
IEC60947-2
Icu/Ics
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Automatic tripping
device
Rating (A) and
Inst. (A)
Number of poles
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Number of poles
Automatic tripping
device
Rating (A) and
Inst. (A)
Solid-state
Adjustable ampere rating
Adjustable short time delay pick up
Fixed instantaneous pick up
Short time delay pick up current
Variation is within ±10% of the setting current
3-4.5-6 In
800 2400-3600-4800
1000 3000-4500-6000
1200 3600-5400-7200
1400 4200-6300-8400
1500 4500-6750-9000
1600 4800-7200-9600
Instantaneous pick up current 20000
NF1600-SS
1600
800-1000-1200-1400-1500-1600
690
25/13
65/33
85/43
85/43
125/63
34
34
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
34
Variation is within ±10% of the setting current
3-4.5-6 In 2-3-4 In
800 2400-3600-4800 1600-2400-3200
1000 3000-4500-6000 2000-3000-4000
1200 3600-5400-7200 2400-3600-4800
1400 4200-6300-8400 2800-4200-5600
1500 4500-6750-9000 3000-4500-6000
1600 4800-7200-9600 3200-4800-6400
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
Variation is within ±10% of the setting current
3-4.5-6 In 2-3-4 In
800 2400-3600-4800 1600-2400-3200
1000 3000-4500-6000 2000-3000-4000
1200 3600-5400-7200 2400-3600-4800
1400 4200-6300-8400 2800-4200-5600
1500 4500-6750-9000 3000-4500-6000
1600 4800-7200-9600 3200-4800-6400
34
Solid-state
Adjustable ampere rating
Adjustable instantaneous pick up
Variation is within ±10% of the setting current
3-4.5-6 In
800 2400-3600-4800
1000 3000-4500-6000
1200 3600-5400-7200
1400 4200-6300-8400
1500 4500-6750-9000
1600 4800-7200-9600
+4000
–2000
