10.11 Interrupt pointer (I)
10.11.1 List of interrupt pointer Nos and interrupt factors
10
DEVICE EXPLANATION
(3) Process CPU
Table10.24 Interrupt pointer number and interrupt factor list (Process CPU)
I No. Interrupt Factors
Priority
Ranking
I No. Interrupt Factors
Priority
Ranking
I0
Interrupt module
(QI60/A1SI61)
1st point 208
I32
*4
Error
*4*5
Errors that stop
operation
1
I1 2nd point 209 I33
SINGLE PS DOWN
*2*3
I2 3rd point 210
I34
UNIT VERIFY ERR.
FUSE BREAK OFF
SP. UNIT ERROR
MULTI CPU ERROR
I3 4th point 211
I4 5th point 212
I5 6th point 213
I35
OPERATION ERROR
SFCP OPE. ERROR
SFCP EXE. ERROR
EX.POWER OFF
I6 7th point 214
I7 8th point 215
I8 9th point 216
I9 10th point 217
I36
ICM. OPE ERROR
FILE OPE. ERROR
I10 11th point 218
I11 12th point 219 I37 Empty
I12 13th point 220 I38 PRG. TIME OVER
I13 14th point 221
I39
CHK instruction
execution
Annunciator detection
I14 15th point 222
I15 16th point 223 I40 to
49
-- Empty --
I16
-- Empty --
I17
I50 to
255
Intelligent
function module
*6*7
Specifies which
intelligent function
module is used with
parameters.
2 to 207
I18
I19
I20
I21
I22
I23
I24
I25
I26
I27
I28
Internal timer
*1
100ms 227
I29 40ms 226
I30 20ms 225
I31 10ms 224
