112
-
'11 • SCM-SM-110
Error code
Remote controller:
LED Green Red
Indoor
Content
E16
Indoor fan motor anomaly
（
FDTC and FDUM series
）
Keeps ashing 1 time ash
Outdoor
– Stays OFF
1. Applicable model
5. Troubleshooting
FDTC and FDUM series only
Diagnosis Countermeasure
NO
YES
YES
Does any
foreign material
intervene in rotational area
of fan propeller?
Is DC280V
detected between - of
fan motor connector
CNM?
Is it normalized?
Does the fan
rotate smoothly when turned
by hand?
YES
NO
NO
NO
YES
（1）
Note (1)  for GND
NO
YES
Power supply reset
Is the fuse F202
（FDUM: F3） blown?
Remove foreign material.
Replace the fan motor.
Check power voltage.
Replace faulty fan motor
and power PCB.
Replace fan motor. (If the
error persists after replacing
the fan motor, replace the
indoor control PCB.)
Malfunction by temporary
noise
2. Error detection method
Detected by rotation speed of
indoor fan motor
3. Condition of Error displayed
When actual rotation speed of
indoor fan motor drops to lower
than 200rpm for 30 seconds
continuously, the compressor
and the indoor fan motor
stop. After 2-seconds, it starts
again automatically, but if this
error occurs 4 times within
60 minutes after the initial
detection.
4. Presumable cause
• Defective indoor power PCB
• Foreign material at rotational
area of fan propeller
• Defective fan motor
• Dust on control PCB
• Blown fuse
• External noise, surge
Note:
