235
-
'11 • SCM-SM-110
8 CHECKING PROCEDURE
8.1 Models SCM71ZJ-S1, 80ZJ-S1
＜Fan motor＞
＜Compressor＞
CNFAN1 on PCB1
③
④
WH
OR
BR
BL
RD
①
②
NO. Output
① 280VDC
② 15VDC
③ 0-6VDC
④ 0-5VDC
Resistance 1.154Ω
U:Pink
V:White
W:Gray
