19
-
Models SRRM25ZE-S, 35ZE-S, 50ZE-S, 60ZE-S
(2) Outdoor unit
Models SCM45ZD-S, 60ZD-S
42.7
42.7
42.7
Drain hole
Elogated hole
(2-12X16)
Terminal block
Gas line service
valve C Unit (ø9.52)
Liquid line service
valve C Unit (ø6.35)
(60 type only)
(60 type only)
Liquid line service
valve B Unit (ø6.35)
Gas line service
valve B Unit (ø9.52)
Liquid line service
valve A Unit (ø6.35)
Gas line service
valve A Unit (ø9.52)
Ground
terminal
314
14
12
850
203.1 510 136.9
476
286.4
12
50
290
49.6
43.5
328
100.3
67.9
67.9
15
640
124
34.6
20º
20º
Unit : mm
Controller
Terminal block
Air outlet
ø 4 × 8(Holes for tapping screws)
B
A
Air inlet
Hanging bolt
(M8 × 4)
35 670 (Suspension bolts pitch)
740
35
515 (Suspension bolts pitch)
455 3030
325
455
106740
150
38
78135
30 230 11 255
236
105
Drain hose
(Connection opening diameter ø16)
220 90 220 105
3014855
1917044
100 540 100
Mark
Description
Model 25,35ZE-S 50,60ZE-S
A
Gas pipe connecting port ø9.52(Flare) ø12.7(Flare)
B
Liquid pipe connecting port ø6.35(Flare)
