'11 • SCM-SM-110
①
①
④
④
②
③
③
＜Thermistor＞
＜Compressor＞
＜Diode module＞
Resistance 0.293Ω
Check a diode module by a mutimeter
set on diode mode.
W
(BL)
V
(WH)
U
(RD)
0℃ 25℃ 50℃ 90℃
Tho-R Black 16.4 5.0 1.8
Tho-D Black 54.8 5.0
Tho-S Black 16.4 5.0 1.8
Tho-A Yellow 32.8 10.0
Tho-AF Black 5.0
Name Color
Resistance(kΩ)
Suction pipe
temp. thermistor (Tho-S)
Outdoor air
temp. thermistor (Tho-A)
Heat exchanger
thermistor (Tho-R)
Power transistor
thermistor (Tho-AF)
Discharge pipe
temp. thermistor (Tho-D)
