1-29
Models SRC50C(H)A, 56C(H)A
42.7
Drain hole
Elogated hole
(2-12X16)
Terminal block
Service valve (Liquide)
Ø6.35 (1/4'')
Service valve (Gas)
Ø12.7 (1/2'')
Ground
terminal
314
14
12
850
203.1
510
136.9
476
286.4
12
50
290
49.6
43.5
328
100.3
15
640
124
34.6
20˚
20˚
