67
Connecting wire with
inverter P.C. board
(CN726)
230V AC
R.V. coil
(CN721)
Output to drive
outdoor fan
motor (CN771)
230V AC
230V AC
Back side of unit
Front side of unit
SUZ-A09VR.TH SUZ-A12VR.TH
Power P.C. board
OC304A --3qxp 04.6.29 8:34 AM Page 67
