Mitsubishi SUZ-A09VR - Page 69

69
SUZ-A18VR.TH SUZ-A24VR.TH
Noise filter P.C.board
{
R.V. coil
230V AC
230V AC
50Hz
Input
230V AC
50Hz Output
{
Power board
{
{
CN901
Electronic
control
board
F912 FUSE
3.15A/250V
NR63 VARISTOR
F911 FUSE
1A/250V
CN902 CN903
CN912
OC304A --3qxp 04.6.29 8:34 AM Page 69
