SIDE PANEL FOR INPUT TERMINAL
Included in the accessories bag is the side panel to cover
the input terminals, located on the bottom right of your
TV. See diagram. Follow the steps below to attach or
remove this side panel:
1. Remove the side panel from the accessories plastic bag
attached to the back of your TV.
2. Route all of the cable downward so the cover can close
over them.
3. Position the three tabs directly opposite the three slots
(see diagram) and gently push toward the front of the
TV.
4. Slide the two push tabs into the slots on the other side
of the terminals until both tabs snap into place.
Result: The side panel neatly covers the input jacks.
Reverse these steps to remove the side panel from the
input terminal.
Slots
Side Panel
Slots for
Push Tabs
Push Tabs
Tabs
Terminal Cover Ventilation for Model WT-
AIR CIRCULATION TIP
When considering the location or position of your TV,
we recommend you place it at least 2” (inches) away from
the wall. Like most electrical equipment and appliances,
better air circulation allows your television to run cooler,
assuring a long, trouble-free life.
At Least 2” (Inches) Away from Wall
Wall
STAND REQUIREMENT
CAUTION: This PTV for use only with Mitsubishi stand MB-. Use
with other stands is capable of resulting in instability causing possible injury.
