Mitsubishi XL1X S L 2 Service Manual

-
7 -
1
w
e
r
t
i
u
y
o
!0
!1
!2
!3
!4
!5
A x4
B x1
L x1
C x1
F x5
I x1
J x1
K x1
H x1
G x2
D x1
E x2
!6
M x1
Note: Technicians must put on a wrist band to protect LCD panel against Static electricity during the repairs.
Number of Screws : The number of Screws holding Parts.
Table 2-6
OPTICAL UNIT1 Part
Fig. 2-6
Parts List : See Parts List Page 5.
Parts Name Number of Screws
q
Lens Cap - - -
w
Lens Unit
A
x4
e
LCD Block
B
x1,
I
x1
r
Thermistor Assy
L
x1
t
Thermal Protector
C
x1,
L
x1
y
Cooling Fan Unit Assy (PBS)
D
x1
u
Cooling Fan Unit Assy (Exhaust)
E
x2
i
Top Cover (Optical)
F
x5
Parts Name Number of Screws
o
Duct1 - - -
!0
Lamp Case Assy
G
x2
!1
Lower Duct
H
x1
!2
Duct2
J
x1
!3
Duct2 (lid)
J
x1
!4
Fan Holder
I
x1,
J
x1
!5
Cooling Fan Unit Assy (Intake)
K
x1
!6
Lamp
M
x1
